The most important machines are listed hereafter



MAIN CNC MACHINING CAPACITIES





CNC DRILLING MILL

  Modelo CNC
Machining dimensions mm Measurs of table mm
Weight on table kg
X Y
Z L I
USED IN TANDEM Juaristi MX 7 RAM Heidenhain TNC 430 M 11.000 3.500 1.000 2.500 2.500 20.000
Juaristi Heidenhain TNC 430 M 11.000 2.500 1.000 2.000 2.000 12.000
MX 5 RAM
Juaristi Heidenhain TNC 430 M 16.075 3.500 1.000     Up to 30.000
MX 5 RAM
  Juaristi Heidenhain TNC 355 1.530 2.885 4.030 2.500 2.000 30.000
  Juaristi Heidenhain TNC 135 1.600 1.000 1.600 1.120 1.100 3.000
  CME Heidenhain TNC 426 CB 2.500 1.200 1.030 2.700 1.000 600
  Correa Heidenhain TNC 410 P 2.500 800 800 2.500 700 4.000
  Correa Fagor 2.500 800 800 2.500 700 4.000
  Soraluce Heidenhain TNC 415 B 4.500 1.600 900 6.500 850 No limit
  Quaser MV204CPL10.000 min-1 Fanuc 1.700 700 700     2.500
  Quaser MV154PL12.000 min-2 Fanuc 1.200 600 600     600



CNC LATHES


  Modelo CNC Medidas en mm
  Diámetro Longitud
  Guruzpe BT 700 Fagor 8050 TC 1.500 6.000
  Geminis GHT5G 2 Fanuc 1.000 4.000
  CMZ Fanuc 520 1.000



OTHER MACHINES


  Many conventional lathes and drilling mills
  Threading machines
  Boring machines
